AIO SERIES
Liquid Cooling ESS
215kWh | Liquid Cooling | All-in-One Design
Efficient, Safe, Stable Energy Storage

AIO series C&I energy storage System is a highly integrated, all-in-one solution with versatile application scenarios. This Liquid-cooled series provides effi­cient, safe, and stable smart energy storage solutions. The cabinet is suitable for various commercial and industrial scenarios, including peak shaving, demand response, backup mode, photovoltaic and energy storage integration, and stable load consumption curves. It also supports applications such as virtual power plants(VPP) and frequency regulation.

Original
Original dust and lint prevention
reduces derating
1.3㎡
High power density, Compact design
Advantages
Safe & Reliable
AI full lifecycle management of battery cells
Efficient & Economical
AI thermal management, efficiency up to 89%
Easy Layout
supporting side by side, back to back layout drawing
Flexible
Support single and 1-to-multi mode
compact footprint
"High power density, occupying only 1.3㎡
Self-developed components
Self-developed ‘3S’ components, optimal management strategy
Smart Management
Cell / pack / cluster / station-level full stack management
Parameters
AIO SERIES
Liquid Cooling ESS
AIO-100K215-L-Y2
AIO-100K215-L-Y2
Cell Capacity / Type
280 Ah / LFP
Pack Parameters
1P48S / 43 kWh
Pack System Configuration
1P240S
DC Operating Voltage Range
672 V ~876 V
System Capacity
215 kWh
Number of Cycles
≥6000@80%SOH
Rated Power
100 kW
Max. Output Power
110 kW
Overload Capacity
110%(45℃), 120% 1min
Grid Voltage
400 V(-15%~+15%)
Grid Access Method
3W / N / PE
Max. system Efficiency
90%
System Dimension(W*H*D)
1100x2450x1400 mm
Weight
≤2500 kg
Cell Certification
GB/T 36276-2018,GB/T 34120-2017, GB/T 34133-2017
IP Rating
IP55
Fire Protection System
Perfluorohexanone+Water Fire Protection
